MOI-V IPTV Streaming Server Chassis (without DVB Tuner cards)
MOI-V IPTV Streaming Server Chassis (without DVB Tuner cards)
- Model: MOI-V
- Weight: 18,000.00g
- Reward Points:2300
In Stock
US$2,300.00
MOI-V is TBS latest professional IPTV streaming server, with flexible x86 CPU (Upto Intel E5 Xeon) and Memory, it support up to 48 TV tuners of different DVB standard in 1U chassis. It can receive live TV signal using built-in TV tuners and stream the channels to your IPTV panel.
MOI-V is a customizable product, you could change CPU, RMA and SSD, and support to install 6 TBS TV tuner card inside, it's a ideal product for IPTV system integrators and TV service operators, allows you to use not only Linux and Ubuntu, but also Windows.Key Features:
- Live SD/HD TV streaming
- Customizable configuration
- Low power consumption
- Supports up to 48 TV tuners (6 TV tuner PCIe cards) of different DVB standard
Specification:
| Size | 1U Chassis |
| Processor | Xeon E3-1231 V3 (default) |
| Memory | 4x 240-pin DDR3 DIMM sockets Default Memory is 1x8G DDR3 |
| Ethernet | 2x Gigabit Ethernet LAN ports 1x RJ45 Dedicated IPMI LAN port |
| Serial ATA | 2x SATA 3.0 (6Gb/s), 4x SATA 2.0(3Gb/s) |
| SSD | 60G SSD |
| Serial Port/Header | 2x COM ports (1 rear, 1 header) |
| FRONT PANEL | Power on |
| Reset | |
| Power LED | |
| HDD LED | |
| Display Interface | 1x VGA D-Sub Connector |
| USB | 2x USB 3.0 ports |
| 6x USB 2.0 ports | |
| PCI-E slot | 6x PCIE1X/4x PCIE1X &1x PCIE4X |
| SBC dimension | 9.6" x 9.6", (24.4cm x 24.4 cm) |
| Operating Systems | Microsoft® Windows 8, Microsoft® Windows 7, |
| Microsoft® Windows® 7/8 embedded Standard, Microsoft® Windows® 7 Embedded Compact | |
| Linux, Ubuntu, | |
| DVB tuner card support | Up to48 TV tuners (6 TV tuner PCIe cards) |
| Pre-installed software | Tvheadend, VDR, MuMuDVB, DVBlast, szap-s2, dvbdate, dvbscan, dvbdstream, dvbsnoop, scan-s2, szap-s2, tzap-t2, LIRC, telnet, ssh, ftp, samba |
